[모니터링] Grafana plugin 설치

Grafana plugins

• 사용자가 원하는 특정 데이터 소스나 시각화 방식을 확장하기 위해 Grafana 플러그인 시스템
• 특정한 시각화 방식이나 차트 유형을 사용하고자 할 때 플러그인을 활용

Zabbix plugins 설치

[root@kvm-host plugins]# pwd
/var/lib/grafana/plugins

[root@kvm-host plugins]# unzip alexanderzobnin-grafana-zabbix-v3.12.2-1-g793129b.zip
Archive:  alexanderzobnin-grafana-zabbix-v3.12.2-1-g793129b.zip
793129b2d602b36b09dc64dab7ec6f5a6f7beb42
   creating: alexanderzobnin-grafana-zabbix-793129b/
   creating: alexanderzobnin-grafana-zabbix-793129b/.circleci/
.
.
[root@kvm-host plugins]# ls -ltr
total 2684
drwxr-xr-x 8 root   root      4096 May 28 15:41 alexanderzobnin-grafana-zabbix-793129b
-rw-r--r-- 1 master master 2742036 Jul 14 08:17 alexanderzobnin-grafana-zabbix-v3.12.2-1-g793129b.zip

[root@kvm-host plugins]# mv alexanderzobnin-grafana-zabbix-793129b/ zabbix

[root@kvm-host plugins]# ls -ltr
total 2684
drwxr-xr-x 8 root   root      4096 May 28 15:41 zabbix
-rw-r--r-- 1 master master 2742036 Jul 14 08:17 alexanderzobnin-grafana-zabbix-v3.12.2-1-g793129b.zip

[root@kvm-host plugins]# pwd
/var/lib/grafana/plugins

[root@kvm-host plugins]# /sbin/grafana-cli --pluginsDir /var/lib/grafana/plugins/ plugins ls
installed plugins:
alexanderzobnin-zabbix-app @ 3.12.2

Restart grafana after installing plugins . <service grafana-server restart>

[root@kvm-host plugins]# systemctl restart grafana-server

Compile 한 서비스 (4000 포트)
/VMS/grafana/grafana-7.1.0/bin/grafana-cli --pluginsDir /VMS/grafana/grafana-7.1.0/data/plugins/ plugins ls
