Piston Pins

Piston pins are mainly used in the diesel engine industry and are cylindrical pins mounted on the piston skirt. Its middle part passes through the small head hole of the connecting rod and is used to connect the piston and the connecting rod. Its function is to transmit the gas force borne by the piston to the connecting rod or to make the small head of the connecting rod drive the piston to move together. To reduce weight, the piston pin is generally made of high-quality alloy steel and made hollow.

The piston pin bears a large periodic impact load under high-temperature conditions, and the design requires high enough mechanical strength, wear resistance, and fatigue resistance.

Specification of Piston Pins
Processing Diameter Range (mm) φ20-φ500
Maximum Processing Length (mm) ≤3000mm
Heat Treatment Type Carburizing/Induction/Nitriding
Linear Tolerance Control Accuracy 0.003
Surface Roughness Rmax0.4 (Ra0.05)
Geometric Tolerance cylindricity 0.003mm
Standard Specifications All items are produced in strict accordance with industry standards or client-specific requirements.

If you are looking for a reliable piston pin manufacturer , please contact us.

For more information about different types of piston pin , please feel free to contact us!

Jinan ZhongChuan Equipment Co., Ltd. (JNZC), established in 1994, is a modern China fastener factory. Our factory covers an area of 80000+ square meters and is located in Jinan Economic Development Zone, Shandong Province, China. It is 350 kilometers away from Qingdao Port, and the transportation is very convenient. We are the member of APQP4WIND. JNZC is a technology-based manufacturing enterprise integrating domestic and foreign trade and is committed to providing reliable machined parts & fastener solutions for global industries.
