Voucher vs. Standard: The Check Type Mistake That Breaks Your QBO Print Setup Every Time
Configuring print settings for checks in QuickBooks Online is a straightforward process once you understand the workflow. Unlike QuickBooks Desktop, QuickBooks Online handles check printing through a cloud-based interface that requires proper alignment setup before you print on actual check stock. This guide walks you through every step, from selecting the correct check type to fine-tuning alignment for perfect results.
Understanding Your Check Stock Options
Before configuring any settings, you must know which type of check stock you are using. QuickBooks Online supports three primary check formats:
| Check Type | Layout | Best Used For |
|---|---|---|
| Standard Checks | Three checks per page | Regular vendor payments, general business expenses |
| Voucher Checks | One check with two stubs per page | Payroll processing, detailed payment records |
| Wallet Checks | Three checks per page (personal format) | Personal use from business accounts |
Your selection here determines how QuickBooks positions the printed information on the page. If you select the wrong check type during setup, your printed checks will not align correctly regardless of how much you adjust the settings.
Phase 1: Initial Printer and Paper Setup
Before touching any settings in QuickBooks, prepare your physical printing environment.
Load Plain Paper First
Never begin alignment testing with actual check stock. Load plain white paper into your printer tray. This allows you to run multiple test prints without wasting expensive pre-printed checks.
Verify Printer Condition
Check that your printer:
- Has adequate ink or toner levels
- Has clean printheads (run a printer cleaning cycle if needed)
- Is set to the correct paper size (typically Letter 8.5" x 11")
- Has no paper jams or feed issues
Quotable Insight: "Getting your paychecks to line up perfectly when printing them from QuickBooks can sometimes feel like trying to assemble a jigsaw puzzle with missing pieces. You want everything to fit just right, but sometimes it requires some tweaking."
Phase 2: Accessing the Check Printing Setup
Step 1: Enter a Check for Printing
Navigate to + New in the left menu and select Check. Complete the check details (payee, amount, account, etc.). The most important field is the Print Later checkbox:
- Checked: The check is added to the print queue. No check number is assigned at this time.
- Unchecked: The check is recorded immediately with a manually entered check number and will not appear in the print queue.
For batch printing, select Print Later for each check as you create it.
Step 2: Navigate to Print Checks
Go to + New and select Print Checks from the dropdown menu. This opens the print queue window where all checks marked for printing appear.
Phase 3: The Alignment Calibration Process
This is the most critical phase. Do not skip these steps.
Step 1: Select Your Check Type
In the Print Checks window, locate the check type dropdown and select the option that matches your physical check stock:
- Standard (3 per page)
- Voucher (1 per page with stubs)
Step 2: Print a Sample Test
Click View preview and print sample. This generates a sample check that prints on your plain paper. Do not load actual check stock yet.
Step 3: Compare Alignment
Hold the printed sample against a blank check from your stock. Hold both up to a light source. Compare where the printed information falls relative to the pre-printed fields on the check.
What to look for:
- Does the payee name align with the "Pay to the Order of" line?
- Does the amount fall within the designated amount box?
- Does the date appear in the correct position?
- Does the memo line align with the memo field?
Step 4: Adjust Offsets (If Needed)
If alignment is off, click No, continue setup. QuickBooks will present alignment adjustment options.
Method A: Using the Alignment Grid
QuickBooks displays a grid interface where you can adjust horizontal and vertical positioning. Each click represents a small incremental movement.
- Horizontal adjustment: Moves content left or right
- Vertical adjustment: Moves content up or down
Make small adjustments—typically 10-20 clicks at a time—and print another sample after each change.
Method B: Manual X/Y Adjustment
If the grid method does not provide sufficient control, navigate to the manual alignment settings where you can enter specific numerical values. Vertical and horizontal adjustments typically range from -0.5 to 0.5 units.
Step 5: Repeat Until Perfect
Continue the cycle of: adjust → print sample on plain paper → compare to check stock → readjust. This iterative process may take 3-5 test prints but ensures perfect alignment.
Once alignment is correct, click Finish Setup. QuickBooks saves these settings for future printing sessions.
Phase 4: Printing Your Checks
Step 1: Load Actual Check Stock
After alignment is confirmed, load your actual check stock into the printer tray. Ensure the checks are oriented correctly (typically face-up, top-first, depending on your printer model).
Step 2: Configure Print Queue Settings
In the Print Checks window:
| Setting | Action |
|---|---|
| Account | Select the bank account from which checks were created |
| Starting check no. | Enter the number of the first check in your printer |
| Transaction Type | Select "Check and Bill Payment" |
| Order checks by | Choose how to sequence printing (Date, Payee, or Order created) |
The starting check number must match the physical check number on the first check in your printer. QuickBooks assigns subsequent numbers in sequence based on the print order you select.
Step 3: Select Checks to Print
Check the box next to each check you want to include in this print run. You can select individual checks or all checks in the queue.
Step 4: Preview and Print
Click Preview and print. Review the preview to ensure the correct checks are selected. Then click Print.
Step 5: Confirm Printing Results
After printing, QuickBooks asks whether the checks printed correctly:
- If successful: Click Done. The checks are marked as printed and assigned their check numbers.
- If issues occurred: Select the option indicating some checks need reprinting. The affected checks remain in the queue for another attempt.
Phase 5: Troubleshooting Common Alignment Problems
Problem: Text Prints Too High or Too Low
Solution: This indicates incorrect vertical alignment. Return to alignment setup and adjust the vertical offset in small increments. Each adjustment typically moves content by 1/16 inch.
Problem: Text Prints Too Far Left or Right
Solution: This requires horizontal adjustment. Use the alignment grid to shift content toward the center. If the amount does not stay within the amount box, continue adjusting until it fits.
Problem: Paychecks and Vendor Checks Have Different Alignment
Solution: QuickBooks may treat paycheck printing as a separate process from vendor check printing. Vendor checks use the standard check alignment settings, while paychecks have their own alignment configuration accessible through Settings → Payroll Settings → Printing section.
Problem: Printer Skews or Jams Checks
Solution: This is a hardware issue, not a QuickBooks problem. Check that:
- The paper guides are snug against the check stock (not too tight, not too loose)
- Your printer supports the thickness of check stock (some inkjet printers struggle with heavy paper)
- The paper feed rollers are clean
Problem: Alignment Changes After Printer or Computer Restart
Solution: Printer drivers sometimes reset to defaults. Save your QuickBooks alignment settings by noting the offset values. If the issue persists, update your printer drivers through Device Manager or the printer manufacturer's website.
Frequently Asked Questions (FAQs)
Q: Can I use any check stock with QuickBooks Online?
A: While you can technically use any check stock, best results come from checks specifically designed for QuickBooks compatibility. Check with your check supplier about "QuickBooks compatible" formats.
Q: Do I need Adobe Acrobat Reader for check printing alignment?
A: QuickBooks Online recommends using Adobe Acrobat Reader for alignment calibration, as some users report better results than printing directly from a browser. However, you can complete the setup using Chrome or other browsers by continuing through the alignment prompts.
Q: How do I print a single check without adding it to the queue?
A: From within the check entry form, click Print Check directly rather than saving it with Print Later selected. This bypasses the print queue and sends the check immediately to your printer.
Q: What should I do if my checks are missing from the print queue?
A: Verify that you selected the correct bank account in the Print Checks window dropdown. Only checks created from that account appear in the queue. Also confirm that each check has the Print Later checkbox selected.
Q: Can I reprint a check that has already been printed?
A: Yes, but you must void the original check first. QuickBooks prevents duplicate check numbers. Void the original, then create a new check with the same details and mark it for printing.
Q: Why do my printed checks look correct on screen but misalign on paper?
A: Screen display does not account for printer hardware variations—paper feed mechanisms, print head positioning, and driver interpretations all affect final output. This is why test printing on plain paper before using actual check stock is essential.
Q: How often should I recalibrate my check alignment?
A: Recalibrate whenever you change printer models, update printer drivers, switch to a different check stock supplier, or notice gradual misalignment developing. Monthly recalibration is recommended for businesses that print checks frequently.
Q: Can I save different alignment settings for different check types?
A: QuickBooks Online stores alignment settings based on the check type (Standard vs. Voucher) you select during setup. If you use both types, run separate alignment calibrations for each and select the correct type before each print run.
Conclusion
Configuring print settings for checks in QuickBooks Online requires a methodical approach that prioritizes alignment calibration before production printing. The process follows a clear sequence: identify your check stock type, prepare your printer with plain paper for testing, access the print queue through the + New menu, run sample prints, adjust horizontal and vertical offsets incrementally until alignment is perfect, then load actual check stock for the final print run.
The most common mistake users make is skipping the test print phase or loading check stock before alignment is confirmed. This wastes expensive check stock and creates frustration. By contrast, running 3-5 test prints on plain paper—adjusting offsets after each—virtually guarantees success on the first attempt with actual checks.
When issues persist, the cause is rarely QuickBooks itself. Printer hardware, outdated drivers, incorrect paper tray settings, or mismatched check stock types are the usual culprits. Addressing these physical variables before returning to software settings saves significant troubleshooting time.
For businesses printing both vendor checks and paychecks, note that these may require separate alignment configurations accessed through different menus within QuickBooks Online. Once calibrated, saved settings persist for future sessions, making subsequent print runs quick and reliable.
