ORIVISION 4K@60 HDMI KVM Optical Fiber Extender
ORIVISION 4K@60 HDMI KVM Optical Fiber Extender
● HDMI 2.1 video supports most popular resolutions up to 4K@60Hz (YUV444)
● HDCP 2.2 and HDCP 2.3 compliance ensures UHD video playback
● Allows remote access of an HDMI video source via a fiber cable up to 10KM
● Support bi-direction audio transmission
● Supports USB2.0 external devices such as keyboards, mouse, USB flash drives, printers, scanners, etc.
● Built-in ESD protection circuit that can effectively prevent electrostatic damage
● Plug-and-play operation with no software required for easy
4K@60 HDMI KVM Fiber Extender
Supports resolutions up to 3840x2160@60Hz(YUV4:4:4)
Standard distance transmission 10KM, distance can be customized
Supports HDMI2.1, HDCP2.2/2.3 and RS-232 control
Supports all USB2.0 Signal Transmission
Plug-and-play operation
4K@60 HDMI+USB2.0 Optical Fiber Extender
OKH901 is a fiber-based extender designed to extend uncompressed 4K@60hz Video signals and USB2.0 devices up to 300m(Using Multimode Dual Core SFP) or 10km(Using Single model core SFP) over duplex fiber cables.
The OKH901 features an HDMI input and output, analog audio input and output, USB2.0 devices KVM, RS-232 control port, and a Gigabit Ethernet port for point to point transmission.
High Availability and Friendly Design
The aluminum shell design protects the interior and provides excellent heat dissipation, further enhancing durability for reliable performance and long life.
Uncompressed 4K UHD Transmission
This HDMI kvm optical extender supports resolutions up to 4K 60Hz (3840 x 2160), providing four times the picture quality of high-definition (1080p). The UHD HDMI Extender supports HDMI 2.1 capabilities, offering 4:4:4 chroma subsampling. This ensures a crystal-clear picture quality and breathtaking color reproduction.
Long Distance Transmission
The Long Range HDMI KVM Extender allows you to extend an HDMI signal up to 10KM over single-mode fiber and 300M over multimode fiber. Not only is this an incredibly long range solution that can extend an HDMI signal across or between buildings, but because fiber optics transmit data using light rather than copper, it will not cause or be affected by electromagnetic Interference (EMI).
Long Distance Transmission
Bi-Directional Audio Signal Transmission
The transmitter supports audio embedding from and external audio source, while the receiver can extract audio from the HDMI signal for use with an external amplifier or powered speakers.
The receiver supports audio embedding from and external audio source, while the transmitter can extract audio from the HDMI signal for use with an external amplifier or powered speakers.
Bi-Directional Audio Signal Transmission
Advanced HDCP/RS232 Extension
HDMI version: HDMI2.1 compatible; LC connection; HDCP 2.2 and HDCP 1.4 Compliance Ensures Uninterrupted HD and UHD Video Playback; Support bi-directional RS232 transport.
Advanced HDCP/RS232 Extension
Support All USB2.0 Signal Transmission
Supports USB2.0 external devices such as keyboards, mouse, USB flash drives, printers, scanners, etc.
Support All USB2.0 Signal Transmission
Easy Installation
Point to Point connection between transmitter and receiver; No IP configuration/drivers/network equipment required;
Easy Installation
Support OEM ODM
OEM: Free print company logo by laser print; MOQ≥1 unit
ODM: Pls send your requirements to us. (info@orivision.cn)
Support OEM ODM
Parameters Of 4K@60 HDMI KVM Optical Fiber Extender
Diagram Of 4K@60 HDMI KVM Optical Fiber Extender
It is ideal for a wide range of applications requiring long distance transmission of high resolution content with the highest quality.
We have mastered the unique technologies in low-bitratew bandwidth transmission, wired/wireless transmission SRT/RTMP/RTMPS/RTSP/RTP/UDP/ONVIF technology, HD decoding multi-format conversion, and streaming media service management. The live video stream hardwares are widely used in the military industry, transportation, emergency management, education recording, communications, new media live broadcast, medical teaching, and other industries.
