Matplotlib - fig, ax

💡 How to use fig, ax in Matplotlib

• Concepts
  • Figure (’fig’) : Represent the entire drawing or canvas. It can contain multiple plots.
  • Axes (’ax’) : Represent a single plot or graph within the figure. A figure can contain multiple axes.
• Form

  fig, ax = plt.subplots()

• Usability
  • Figure : Used to set the overall size, resolution, and layout of the entire plot
  • Axes : Used to set the data, labels, titles, and ranges of individual plots.
• Examples
  • Ex1) Single Plot

    import matplotlib.pyplot as plt
    import numpy as np

    # Create data
    x = np.linspace(0, 10, 100)
    y = np.sin(x)

    # Create Figure and Axes
    fig, ax = plt.subplots()

    # Plot data
    ax.plot(x, y)

    # Set Axes labels and title
    ax.set_xlabel('X axis')
    ax.set_ylabel('Y axis')
    ax.set_title('Sine Function Plot')

    # Set Figure size
    fig.set_size_inches(10, 6)

    # Show plot
    plt.show()

  • Ex2) Multiple Subplo

    import matplotlib.pyplot as plt
    import numpy as np

    # Create data
    x = np.linspace(0, 10, 100)
    y1 = np.sin(x)
    y2 = np.cos(x)
    y3 = np.tan(x)
    y4 = -np.sin(x)

    # Create a 2x2 grid of subplots
    fig, axs = plt.subplots(2, 2)

    # Plot data in each subplot
    axs[0, 0].plot(x, y1)
    axs[0, 1].plot(x, y2)
    axs[1, 0].plot(x, y3)
    axs[1, 1].plot(x, y4)

    # Set titles for each subplot
    axs[0, 0].set_title('Sine')
    axs[0, 1].set_title('Cosine')
    axs[1, 0].set_title('Tangent')
    axs[1, 1].set_title('Negative Sine')

    # Adjust layout
    fig.tight_layout()

    # Show plot
    plt.show()

🍇 Benefits of Using ‘fig’ and ‘ax’ in Matplotlib

• Clear Structure and Organization
  • Separation of Concerns : ‘fig’ represents the entire figure, while ‘ax’ represents individual plots. This clear separation allows for better organization and management of the plotting code.
  • Hierarchical Design : By distinguishing between the figure and its axes, it is easier to apply different settings and modifications at different levels.
• Flexibility in Layout Management
  • Multiple Subplots : ‘plt.subplots()’ allows you to create multiple subplots within a single figure, making it easy to compare different datasets or different views of the same data.
  • Custom Layouts : Using ‘GridSpec’, you can create complex layouts with varying subplot sizes and positions, giving you control over the presentation of your data.
• Enhanced Customization
  • Individual Plot Control : Each ‘ax’ object can be customized independently, allowing you to set labels, titles, ticks, limits, and styles for each subplot without affecting others.
  • Global Settings : The ‘fig’ object can be used to set properties that affect the entire figure, such as size, DPI, and overall layout, ensuring consistency across all subplots.
• Improved Code Readability and Maintenance
  • Modular Code : By separating figure-level and axes-level customizations, the code becomes more modular and easier to understand, debug, and maintain.
  • Reusable Components : You can define common customizations for ‘fig’ and ‘ax’ and reuse them across different plots, reducing code duplication and enhancing consistency.
• Advanced Plotting Capabilities
  • Annotations and Insets : You can add annotations, and other custom elements to specific axes, providing more informative and detailed visualizations.
  • Interactive Features : The ‘ax’ object supports interactive features like zooming and panning, making it easier to explore the data within individual subplots.
• Integration with Other Libraries
  • Seamless Integration : ‘fig’ and ‘ax’ are compatible with other plotting libraries and tools in the Python ecosystem, such as Seaborn and Pandas plotting, allowing for enhanced functionality and customization.

    #Example demonstrating some of these benefits:

    import matplotlib.pyplot as plt
    import numpy as np

    # Create data
    x = np.linspace(0, 10, 100)
    y1 = np.sin(x)
    y2 = np.cos(x)

    # Create a figure and a 2x1 grid of subplots
    fig, axs = plt.subplots(2, 1, figsize=(8, 6))

    # Plot data in the first subplot
    axs[0].plot(x, y1, label='Sine')
    axs[0].set_title('Sine Function')
    axs[0].set_xlabel('X axis')
    axs[0].set_ylabel('Y axis')
    axs[0].legend()

    # Plot data in the second subplot
    axs[1].plot(x, y2, label='Cosine', color='r')
    axs[1].set_title('Cosine Function')
    axs[1].set_xlabel('X axis')
    axs[1].set_ylabel('Y axis')
    axs[1].legend()

    # Set a global title for the figure
    fig.suptitle('Trigonometric Functions')

    # Adjust layout for better spacing
    fig.tight_layout(rect=[0, 0, 1, 0.95])

    # Show plot
    plt.show()


🍐 Drawbacks to consider

• Complexity for Simple Plots
  • Overhead : For simple, single plots, using ‘fig’ and ‘ax’ can add unnecessary complexity. The additional lines of code to create and manage these objects might be overkill when a straightforward ‘plt.plot()’ could suffice.
• Steeper Learning Curve
  • Understanding the Hierarchy : New users might find the concept of figures and axes confusing initially. Understanding how these objects interact and how to manipulate them requires a bit more effort compared to basic plotting functions.
  • More Code to Write : Managing ‘fig’ and ‘ax’ objects often requires writing more code, which can be intimidating for beginners who just want to create quick plots.
• Verbosity
  • Increased Code Length : Using ‘fig’ and ‘ax’ can lead to more verbose code. This can be seen as a drawback when the goal is to create quick visualizations without much customization.
  • Repetitive Code : If not managed properly, customization of individual ‘ax’ objects can lead to repetitive code, especially when dealing with multiple subplots that share similar settings.
• Potential for Mismanagement
  • Coordination Between ‘fig’ and ‘ax’ : Improper coordination between figure and axes can lead to issues like overlapping plots or improper layout management, which can make debugging more difficult.
  • Statefulness : Matplotlib's state-based interface (using ‘plt’) can sometimes interfere with the object-oriented approach (’fig’ and ‘ax’), leading to unexpected behaviors if both styles are mixed without careful management.
• Performance
  • Resource Intensive : For very large figures with many subplots, managing multiple axes can become resource-intensive, potentially impacting performance. This is especially true if each subplot involves complex rendering or large datasets.
  • Memory Usage : Creating and holding onto many figure and axes objects can increase memory usage, which might be a concern in memory-constrained environments.

    #how using 'fig' and 'ax' can lead to verbose and potentially confusing code for simple tasks

    import matplotlib.pyplot as plt
    import numpy as np

    # Simple data
    x = np.linspace(0, 10, 100)
    y = np.sin(x)

    # Using fig and ax for a single plot
    fig, ax = plt.subplots()
    ax.plot(x, y)
    ax.set_title('Sine Function')
    ax.set_xlabel('X axis')
    ax.set_ylabel('Y axis')

    plt.show()

    ```
