METAL-ENCLOSED SWITCHGEAR

Box-type fixed AC metal-enclosed switchgear (hereinafter referred to as switchgear) is suitable for 3.6~12 KV three-phase AC 50Hz systems as a device for receiving and distributing electrical energy. This metal-enclosed switchgear is suitable for places with frequent operations and for the renovation of switchgear equipped with oil switches. A metal enclosed switchgear busbar system is a single busbar system and a single busbar sectioning system.

Our high voltage switchgear for sale complies with and meets the requirements of GB/T 3906-2020, DL404-2018, and the international standard IEC62271-200:2003. The metal-enclosed switchgear is aesthetically pleasing, compact in size, and has a complete and reliable anti-misoperation function.

Features
Box-type fixed metal-enclosed switchgear, the cabinet frame is welded with angle steel, and the cabinet is divided into circuit breaker room, busbar room, cable room, and relay room, etc. The rooms are separated by steel plates.

Diagram

When placing an order, the user must specify:

The main connection scheme and single-line system diagram.

The secondary circuit wiring principle diagram and the terminal arrangement diagram. If there is no terminal arrangement diagram, metal enclosed switchgear shall be supplied in accordance with the manufacturer's regulations.

The model, specification, and quantity of the electrical components in the switch cabinet.

The material and specification of the main busbar and branch busbar. Otherwise, metal enclosed switchgear will be supplied in accordance with the manufacturer's regulations.

If the switch cabinet is to be used in special environmental conditions, this should be stated when placing the order.

When accessories and spare parts are required, metal enclosed switchgear types and quantities should be specified.

The external structure diagram of the high-current overhead incoming line cabinet

Dimensions and structural diagram

Busbar compartment

2Pressure relief channel

Instrument compartment

Combined switch compartment

Manual operation and interlocking mechanism

Main switch compartment

Electromagnetic or spring operating mechanism

Ground busbar

Cable compartment
