How Merkle Root is Made

What is Merkle Root?

A hash that represents the root of the Merkle tree, hashed from transactions consisting of a block.

Component	Description
Block Header
Previous Block Hash	A 256-bit hash value that points to the previous block in the chain, effectively linking the blocks together.
Merkle Root	A hash value that represents the root of the Merkle tree, which is a data structure that summarizes all the transactions in the block.
Timestamp	The approximate time when the block was created/mined.
Nonce	A random value used in the mining process to solve the proof-of-work puzzle.
Difficulty Target	A value that determines the difficulty of the proof-of-work puzzle for that block.
Version	Indicates the version of the block validation rules that should be followed.
Block Body
Transaction Counter	A simple count of the number of transactions included in the block.
Transactions	A list of valid transactions that are being recorded in the block. Each transaction includes details like the sender's and recipient's addresses, the amount being transferred, and other metadata.

This table clearly separates the components of the block header and the block body, along with their respective descriptions. The block header contains metadata that links the block to the previous block and secures the integrity of the blockchain, while the block body contains the actual transactions being recorded on the blockchain.

55,123rd Blockchain Node

Making a Merkle Hash: A Step-by-Step Guide

In the world of blockchain, Merkle trees play a crucial role in ensuring the integrity and efficient verification of transactions. A Merkle hash, also known as the Merkle root, is the hash value at the root of this tree, which summarizes all the transactions in a block. Let's dive into the process of creating a Merkle hash using an example from the 55,123rd block on the blockchain.

Given:

• Transaction 1 hash: fb538d4e3d518e6e675e246855374d0b72e1881425627578aaa4719c01cf7489
• Transaction 2 hash: 29fa3359414a2090d93ec4db049f951a003b0be26426ac806f866e712665a38b

Step 1: Convert the hash from big endian to little endian

In the blockchain, hashes are typically stored in big-endian format. However, for the purpose of creating a Merkle hash, we need to convert them to little-endian format.

Transaction 1 hash (small-endian): 8974CF019C71A4AA787562251488E1720B4D375568245E676E8E513D4E8D53FB

Transaction 2 hash (small-endian): 8BA36526716E866F80AC2664E20B3B001A959F04DBC43ED990204A415933FA29

Step 2: Concatenate the hashed digits converted to little endian

We now concatenate the two small-endian hashes into a single string:

8974CF019C71A4AA787562251488E1720B4D375568245E676E8E513D4E8D53FB8BA36526716E866F80AC2664E20B3B001A959F04DBC43ED990204A415933FA29

Step 3: Hash the result using SHA256 twice

The concatenated string is then hashed using the SHA256 algorithm twice (double SHA256), as per the Bitcoin protocol.

SHA256(SHA256(concatenated_string)) = 763ed200a5474a45dc0d196def0f3579d22d8912f1fa0ab3064e627e66fa08a8

Step 4: Convert the hash from Step 3 from little endian to big endian

Finally, we convert the hash obtained in Step 3 from little-endian to big-endian format to get the final Merkle hash.

Merkle hash (big-endian): A808FA667E624E06B30AFAF112892DD279350FEF6D190DDC454A47A500D23E76

To visualize the process, here's the binary tree representation of the hash nodes:

       A808F
     /      \
  fb538    29fa3

In this way, the Merkle hash acts as a compact summary of all the transactions in a block, allowing efficient verification and ensuring the integrity of the blockchain. Any change in the transactions would result in a different Merkle hash, breaking the chain and making the block invalid.

Let's practice one more time. Now, there are 4 transaction IDs. The steps the same following the binary tree method.

100,000 Blockchain Node

Given:
1) 8c14f0db3df150123e6f3dbbf30f8b955a8249b62ac1d1ff16284aefa3d06d87
2) fff2525b8931402dd09222c50775608f75787bd2b87e56995a7bdd30f79702c4
3) 6359f0868171b1d194cbee1af2f16ea598ae8fad666d9b012c8ed2b79a236ec4
4) e9a66845e05d5abc0ad04ec80f774a7e585c6e8db975962d069a522137b80c1d

Step 1: Convert the hashes from big endian to little endian

1) 876da0d3efa4281ff1d1c12ab6498a5a958b0ff3bb3d6f123e1250f13ddb0f148c
2) c40297f730dd7b5a99567eb8d27b78758f60750725c92209d02d401389525bf2ff
3) c46e239ab7d28e2c019bd66daefa8e59a66ef1f21aeebc94d1b17181860ff03965
4) 1d0cb83721529a062d9675b98d6e5c587e4a770fc84ed00abc5a5de04568a6e9

Step 2: Concatenate the hashed digits converted to little endian

1) 876da0d3efa4281ff1d1c12ab6498a5a958b0ff3bb3d6f123e1250f13ddb0f148cc40297f730dd7b5a99567eb8d27b78758f60750725c92209d02d401389525bf2ff
2)
c46e239ab7d28e2c019bd66daefa8e59a66ef1f21aeebc94d1b17181860ff039651d0cb83721529a062d9675b98d6e5c587e4a770fc84ed00abc5a5de04568a6e9

Step 3: Hash the result using SHA256 twice

1) 15b88c5107195bf09eb9da89b83d95b3d070079a3c5c5d3d17d0dcd873fbdacc
2)
49aef42d78e3e9999c9e6ec9e1dddd6cb880bf3b076a03be1318ca789089308e

Step 4: Convert the hash from Step 3 from little endian to big endian

1) (little-endian): 15b88c5107195bf09eb9da89b83d95b3d070079a3c5c5d3d17d0dcd873fbdacc
(big-endian):
CCDAFB73D8DCD0173D5D5C3C9A0770D0B3953DB889DAB99EF05B1907518CB815
2)
(little-endian): 49aef42d78e3e9999c9e6ec9e1dddd6cb880bf3b076a03be1318ca789089308e
(big-endian): 8E30899078CA1813BE036A073BBF80B86CDDDDE1C96E9E9C99E9E3782DF4AE49

Step 5: Repeat the process above
5-1. Big-endian to small endian
1)
(big-endian):
CCDAFB73D8DCD0173D5D5C3C9A0770D0B3953DB889DAB99EF05B1907518CB815
(little-endian):
15b88c5107195bf09eb9da89b83d95b3d070079a3c5c5d3d17d0dcd873fbdacc
2)
(big-endian): 8E30899078CA1813BE036A073BBF80B86CDDDDE1C96E9E9C99E9E3782DF4AE49
(little-endian):
49aef42d78e3e9999c9e6ec9e1dddd6cb880bf3b076a03be1318ca789089308e

5-2. Concatenate the hashed digits converted to little endian
15b88c5107195bf09eb9da89b83d95b3d070079a3c5c5d3d17d0dcd873fbdacc49aef42d78e3e9999c9e6ec9e1dddd6cb880bf3b076a03be1318ca789089308e

5-3. Hash the result using SHA256 twice
6657a9252aacd5c0b2940996ecff952228c3067cc38d4885efb5a4ac4247e9f3

5-4. Convert the hash from Step 5-3 from little endian to big endian
F3E94742ACA4B5EF85488DC37C06C3282295FFEC960994B2C0D5AC2A25A95766

    	  F3E94
    	/      \
	CCDAF     8E308
	/   \     /   \
8c14f fff25 6359f e9a66
