[D3D] Material

vector·2025년 11월 23일

Material

3D그래픽에서 Mesh의 표면이 어떻게 보일지를 결정하는 데이터 집합
물체의 빛에 대한 정보와 Texture정보를 가지고 있음
Clone() : A, B 물체가 하나의 Material을 가지고 있을때 B의 Material을 수정하면 A의 Material도 같으 수정되는 현상을 막기 위해 사용되는 함수, 서로 다른 Material을 사용하면 되지만 같은 Material에서 수정할 경우에 사용

Material.h

#pragma once
#include "ResourceBase.h"

class Material : public ResourceBase
{
	using Super = ResourceBase;
public:
	Material();
	virtual ~Material();

	shared_ptr<Shader> GetShader() { return _shader; }

	MaterialDesc& GetMaterialDesc() { return _desc; }
	shared_ptr<Texture> GetDiffuseMap() { return _diffuseMap; }
	shared_ptr<Texture> GetNormalMap() { return _normalMap; }
	shared_ptr<Texture> GetSpecularMap() { return _specularMap; }


	void SetShader(shared_ptr<Shader> shader);
	void SetDiffuseMap(shared_ptr<Texture> diffuseMap) { _diffuseMap = diffuseMap; }
	void SetNormalMap(shared_ptr<Texture> normalMap) { _normalMap = normalMap; }
	void SetSpecularMap(shared_ptr<Texture> specularMap) { _specularMap = specularMap; }

	void Update();

	shared_ptr<Material> Clone();

private:
	friend class MeshRenderer;

	MaterialDesc _desc;

	shared_ptr<Shader> _shader;
	shared_ptr<Texture> _diffuseMap;
	shared_ptr<Texture> _normalMap;
	shared_ptr<Texture> _specularMap;

	ComPtr<ID3DX11EffectShaderResourceVariable> _diffuseEffectBuffer;
	ComPtr<ID3DX11EffectShaderResourceVariable> _normalEffectBuffer;
	ComPtr<ID3DX11EffectShaderResourceVariable> _specularEffectBuffer;
};

Material.cpp

#include "pch.h"
#include "Material.h"

Material::Material() : Super(ResourceType::Material)
{
}
Material::~Material()
{
}

void Material::SetShader(shared_ptr<Shader> shader)
{
	_shader = shader;

	_diffuseEffectBuffer = shader->GetSRV("DiffuseMap");
	_normalEffectBuffer = shader->GetSRV("NormalMap");
	_specularEffectBuffer = shader->GetSRV("SpecularMap");
}

void Material::Update()
{
	if (_shader == nullptr)
		return;

	RENDER->PushMaterialData(_desc);

	if (_diffuseMap)
		_diffuseEffectBuffer->SetResource(_diffuseMap->GetComPtr().Get());

	if (_normalMap)
		_normalEffectBuffer->SetResource(_normalMap->GetComPtr().Get());

	if (_specularMap)
		_specularEffectBuffer->SetResource(_specularMap->GetComPtr().Get());
}

shared_ptr<Material> Material::Clone()
{
	shared_ptr<Material> material = make_shared<Material>();

	material->_desc = _desc;
	material->_shader = _shader;
	material->_diffuseMap = _diffuseMap;
	material->_normalMap = _normalMap;
	material->_specularMap = _specularMap;
	material->_diffuseEffectBuffer = _diffuseEffectBuffer;
	material->_normalEffectBuffer = _normalEffectBuffer;
	material->_specularEffectBuffer = _specularEffectBuffer;


	return material;
}

MeshRenderer.h

MeshRenderer에서 가지고 있던 Texture와 Shader를 Material로 변경
Update()에서 Material에서 Shader를 가져오고 Material->Update()형식으로 변경

#pragma once
#include "Component.h"
#include "Material.h"

class Mesh;
class Shader;
class Material;

class MeshRenderer : public Component
{
	using Super = Component;
public:
	MeshRenderer();
	virtual ~MeshRenderer();

	virtual void Update() override;

	void SetMesh(shared_ptr<Mesh> mesh) { _mesh = mesh; }
	void SetMaterial(shared_ptr<Material> material) { _material = material; }

private:
	shared_ptr<Mesh> _mesh;
	shared_ptr<Material> _material;
};

MeshRenderer.cpp

void MeshRenderer::Update()
{
	if (_mesh == nullptr || _material == nullptr)
		return;
	auto shader = _material->GetShader();
	if (shader == nullptr)
		return;

	_material->Update();

	auto world = GetTransform()->GetWorldMatrix();
	RENDER->PushTransformData(TransformDesc{ world });

	uint32 stride = _mesh->GetVertexBuffer()->GetStride();
	uint32 offset = _mesh->GetVertexBuffer()->GetOffset();

	DC->IASetVertexBuffers(0, 1, _mesh->GetVertexBuffer()->GetComPtr().GetAddressOf(), &stride, &offset);
	DC->IASetIndexBuffer(_mesh->GetIndexBuffer()->GetComPtr().Get(), DXGI_FORMAT_R32_UINT, 0);

	shader->DrawIndexed(0, 0, _mesh->GetIndexBuffer()->GetCount(), 0, 0);
}

17. MaterialDemo.cpp

Init()초반에서 Material생성 및 초기화
ResourceManager를 통해서 리소스 추가
obj2에서 Material을 Clone()으로 만들어서 하나가 수정될 때 두개가 같이 수정되는 문제 방지

void MaterialDemo::Init()
{
	RESOURCES->Init();
	_shader = make_shared<Shader>(L"13.Lighting.fx");

	// Material
	{
		shared_ptr<Material> material = make_shared<Material>();
		{
			material->SetShader(_shader);
		}
		{
			auto texture = RESOURCES->Load<Texture>(L"Veigar", L"../Resources/Textures/veigar.jpg");
			material->SetDiffuseMap(texture);
		}

		MaterialDesc& desc = material->GetMaterialDesc();
		desc.ambient = Vec4(1.f);
		desc.diffuse = Vec4(1.f);

		RESOURCES->Add(L"Veigar", material);
	}

	// Camera
	_camera = make_shared<GameObject>();
	_camera->GetOrAddTransform()->SetPosition(Vec3{ 0.f, 0.f, -10.f });
	_camera->AddComponent(make_shared<Camera>());
	_camera->AddComponent(make_shared<CameraScript>());

	// Object
	_obj = make_shared<GameObject>();
	_obj->GetOrAddTransform();
	_obj->AddComponent(make_shared<MeshRenderer>());
	{
		auto mesh = RESOURCES->Get<Mesh>(L"Sphere");
		_obj->GetMeshRenderer()->SetMesh(mesh);
	}
	{
		auto material = RESOURCES->Get<Material>(L"Veigar");
		_obj->GetMeshRenderer()->SetMaterial(material);
	}

	// Object2
	_obj2 = make_shared<GameObject>();
	_obj2->GetOrAddTransform()->SetPosition(Vec3{ 0.5f, 0.f, 2.f });
	_obj2->AddComponent(make_shared<MeshRenderer>());
	{
		auto mesh = RESOURCES->Get<Mesh>(L"Cube");
		_obj2->GetMeshRenderer()->SetMesh(mesh);
	}
	{
		auto material = RESOURCES->Get<Material>(L"Veigar")->Clone();

		MaterialDesc& desc = material->GetMaterialDesc();
		desc.ambient = Vec4(0.f);
		desc.diffuse = Vec4(0.f);

		_obj2->GetMeshRenderer()->SetMaterial(material);
	}

	RENDER->Init(_shader);
}
